Intelligent touch screen digital portable walk through metaldetector
Feature:
1.specifically for roads, railways, customs, terminal and the design of public places
2.specialized operating platform
3.features high-performance network
4.user free to choose the mode of training
5.Matching crisis can be integrated information analysis system (security black box)
6.matching explosives and drug detection X-ray automatic identification software system (also known as-Auto sight)
7.through the EU CE Certification /Ministry of Public Security through the National Detected / international ISO9001 certification /ISO14001 environmental certification /Chinese Government's Radiation Safety Certification
Image System:
X-ray Sensor: L-Shaped Photodiode Array (multi-energetic) , 240bit Deep
Image Processing: Edge enhancement, image strengthening, image lightening,, reducing darkening, image returning, image retrieval.
Image Max Resolution: 1024 * 1280 pixel
Image storage: Storage 100000 pictures in real time.
Zones & Zoom: 1-9 Image regions, 2,4,8,16 Times Enlarge, Whole screen continuous observation
High-energy/low energy : switch from high energy to low energy
Specifications:
| Tunnel Size | 500(W)×300(H)mm |
| Conveyor Speed | 0.22m/s |
| Conveyor Max Load | 150 kg |
| Single inspection dosage | < 1.22µGy |
| Wire Resolution | 0.101mm metal line |
| Steel Penetration | 34MM armor plate |
| Film Safety | For ISO 1900 |
| Maximum leakage radiation | <0.05µGY/H |
| X-RAY GENERATOR | Vertically Upward |
| Tube Current | 0.4~0.2MA(adjustable) |
| Anode Voltage | 100~160 kV (adjustable) |
| Angle | 60° |
| Generator cooling/working periods | Sealed oil bath with forced air/100%
OPERATING ENVIRONMENT |
| Storage Temperature | -20ºC to 60ºC |
| Operating Temperature | 0ºC to 45ºC |
| Relative Humidity | 20 to 95% non-condensing |
| System Power | 220 VAC (±10%) 50±3HZ |
| Power wastage | 1.0 KW (Max) |
| Noise | <55dB(A) |
|
|
Intelligent touch screen digital portable walk through metaldetector Images
|
